3 Phase Tricanter Poultry Oil / animal oil Extraction Decanter Centrifuge
Instruction:
It is wide application range, work continuously, large processing capacity, low cost, convenient
maintenance and so on. It is the best equipment for separating solid-liquid.
Fresh fish are sent by spiral conveyer into the cooking machine for stewing, and then delivered to the rolling mill after thoroughly stewed, and the fishmeal is produced after rolled fish are dried in a dryer. There are oil water and fish scraps in the fish soup, after being extracted, if the fish oil and fish scraps are sent back to the dryer, it is called through-dewatering, if they are not sent back to be evaporated, it is called half-dewatering. As normal fishmeal plants do not have sewage treatment device, considering the environmental requirement, most of them adopts the through-dewatering method. There are various technologies in extracting fish scraps and fish oil from the fish soup, among which a relatively traditional one is to extract fish oil by several settling ponds, another one is to extract fish scraps by two-phase Horizontal Decanter Centrifuge and then extract the fish oil by disc stack centrifuge, another one is to extract the fish scraps and fish oil for one time by three-phase Horizontal Decanter Centrifuge.
The water content of the fish oil /poultry oil/ anima oil from our three-phase fish oil separator can be controlled below 2%, preferably at 1%, and it can be adaptive without manual adjustment. It is not different for different species. Our machine Compared with other manufacturers, the installed power is the same and the processing capacity is large.
Technical parameters
| Type | Bowl diameter(mm) | Bowl length/ Bowl diameter | Bowl speed (r/min) | Main Power(Kw) |
| LWS355 | 355 | 3.3-4.5 | 4000 | 15-18.5 |
| LWS420 | 420 | 4.1 | 3600 | 22 |
| LWS500 | 500 | 4.2 | 3000 | 30 |
| LWS530 | 500 | 4.2 | 3000 | 30 |
| LWS580 | 580 | 4.1 | 2800 | 45 |
| LWS620 | 620 | 4 | 2800 | 45 |
| Note: In case of differences between the table and the user manual, the latter shall prevail. |
working principle
Application
It is widely used in chemical industry, light industry, medicine, food, paper making, mining and other industries.
For LW decanter centrifuge, we have two different types, one is LW decanter centrifuge , which is two phase centrifuge(solid liquid centrifuge), another is three phase centrifuge (solid liquid liquid centrifuge.)
1) City tap water, domestic sludge dewatering;
2) Oil drilling mud dewatering;
3) Sludge Oil Recovery;
4) Fruit juice separation
5) Soy protein dehydration;
6) Refinery sludge concentrated dehydration;
7) Distiller ‘s grains dehydration;
8) Paper, printing and dyeing wastewater separation;
9) Medical sludge dewatering;
10) Plant oil clarification and separation;
11) Cosmetic clarification and separation;
12) Bleaching powder separation.
13) coal tar separation
14) fish oil. poultry oil, beef oil, pork oil animal oil ect
Brief Introduction of Three-Phase Fish Oil Separator
Nanjing FiveMen Machinery Manufacture Co., Ltd. is a joint-equity company engaging in the design, manufacture, sale and services of centrifuges .
Our three-phase fish oil separators have been used by hundreds of fishmeal manufacturers in coastal provinces such as Liaoning, Hebei, Shandong, Jiangsu, Zhejiang, Fujian, Guangdong, Guangxi, and Hainan. Excellent product quality, advanced structural design, fast after-sales service, reasonable price, and optimal comprehensive cost performance make us a latecomer to the fishmeal industry. With the help of the majority of fishmeal producers, the current fish oil distribution The number of machine users is at the forefront of our peers. With the help of the vast number of exporters, our oil separators have been successfully exported to North America, Eastern Europe, East Asia, Southeast Asia, South Asia, Middle East, South America, North America, West Africa, East Africa and South Africa.
We have passed the ISO9000 quality system certification of China Classification Society. The machines used in inland rivers and ocean transportation have obtained CCS approval certificates, and the products used in fishing vessels have also passed the fish inspection. Over the years, we have won the honorary titles of "Quality Products of Jiangsu Province", "Quality, Service, Credit AAA Demonstration Unit of Jiangsu Province", "Star Enterprise of Jiangsu Province" and "Quality and Credit AAA Brand Enterprise of Jiangsu Province".
Quality policies: Excellent Quality, Leading Technology, Sincere Operation and Customer Satisfaction. Customer satisfaction is our quality policy. We provide high quality oil separators by providing oil separator products with advanced structure, low vibration, low noise and high reliability. to achieve the common development of us and our customers.
